typical Control Panel Options Wiring Options Pre-wired outlets for heater power: Female twist lock style panel mount connectors and male plugs can be added to the exterior of the enclosure for circuits of 480 VAC and 30 Amp and under. Pre-wired panel jacks for temperature sensors: Female panel mount jack connectors and plugs can be added to…
Standard NEMA (National Electrical Manufacturers’ Association) Enclosure Ratings Guide Comparison of Indoor Rated Enclosures Provides a degree of protection against the following conditions: Type of Enclosure 1 4 4X 7 12 Incidental contact with enclosed equipment X X X X X Falling dirt X X X X X Falling liquids and light splashing X…
Thermocouple Wire Color Code & Specifications For United States, Canada & Mexico Thermocouple Wire ANSI Codes, Color Codes and Specifications ANSI Code Color Code Positive (+) Lead Negative (-) Lead Temperature Range Initial Calibration Tolerances Standard °C (whichever is greater) Special °C (whichever is greater) J Iron Constantan (45% Nickel, 55% Copper) 32-1382°F (0-750°C) ±2.2°C…
