Model TBC-41 Temperature Controller
TBC-41 Design Features
- Easy to use high performance at a low price
- Fuzzy logic PID Autotune heat and cool control
- Fast A-D sampling rate (5 samples/second)
- Universal input, field configurable (Type J T/C default, PT100, mA, V) witih high accuarcy 18-bit D-A
- Analog output (linear current or voltage) uses high accuracy 15-bit D-A Converter
- Optional RS-232 or RS-485 communications interface
- Universal input power— 90-250 VAC 50/60HZ or 11-26 VAC/VDC
- Programming port provided on board
- Supports manual control & auto-tune functions
- Wide variety of alarm mode selections
- Lockout Protection
- Bumpless transfer
- Soft-start ramp and dwell timer
- Bright 0.55″ (14 mm) red LED process display
